Please verify that the part number and pictures match the part you are replacing before ordering.
Models/Applications:
Specification:
Coil Voltage: 12VDC
Contact Form: SPDT (1 Form C)
Contact Rating (Current): 40 A
Switching Voltage: 14VDC - Nom
Coil Current: 151 mA
Coil Type: Non-Latching
Features: Resistor
Termination Style: Plug In, Quick Connect - 0.250" (6.3mm)
Operate Voltage: 7.2 VDC
Release Voltage: 1.2 VDC
Operate Time: 7 ms
Release Time: 2 ms
Operating Temperature: -40°C ~ 125°C
Coil Resistance: 79.5 Ohms
Fit For John Deere Tractor: 130, 170, 175, 180, 185, 316, 318, 420, 425, 430, 445, 455, F910, F930, GX70, RX63, SRX75
Fit For New Holland Baler: 660
Fit For CASE Tractor: 2590
Fit For CASE Planter: 955
Fit For CASE Trencher: 760
Replacement Part Number(s): 882751A1, 3854138, 73040, 828151, 828151A1, 882751A2, 87414BP, B VF4-55F11, 0332204174, 8-1393305-6, 84411012, VF4-55F11-S01, VF455F11S01, A165315, 139026A1, 139026A2, 80782996, 80859973, A167492, A167627, BN24056, L108425
